SKU: PR1KSG30
PARAMETER
Frequency range
1575 ~ 1602 MHz
Polarization
RHCP
Gain
2.0 dBi
VSWR
1.5
Impedance
50 ?
Axial ratio
3 dB
LNA gain
26 ? 2 dB
LNA noise figure
1.5 dB
Supply voltage
2.2 ??5.0 VDC
Current consumption
5 ??15 mA
LNA VSWR
2.0
Cable
RG174, 3000 mm
Connector type
SMA Male
Mounting method
Adhesive
Operating temperature
?40 ~ +85
Operating relative humidity
95 %
RoHS compliant
?
