Key Applications
- Web Server, Firewall Application
- Data Center Optimized, Value IaaS
- Cloud Computing, Compact Server
- DNS & Gateway Servers, Firewall Application
- CDN, Edge Nodes
Key Features
- Dual sockets E (LGA-4677) 4rd Gen Intel® Xeon® Scalable processors
- 16 DIMMs up to 4TB 3DS ECC DDR5-4800: RDIMM
-
- 4 PCIe 5.0 x16 FHHL (OR) 2 PCIe 5.0 x16 FHHL and 4 PCIe 5.0 x8 FHHL;
- 2 PCIe 5.0 x16 AIOM (OCP 3.0);
- 2 PCIe 5.0 x4 NVMe M.2
- Dual AIOM with NCSI (OCP 3.0) for networking, 1 dedicated IPMI LAN
- 12x 3.5/2.5″ hot-swap hybrid NVMe/SATA/SAS drive bays
- 3 heavy duty fans with optimal fan speed control, 1 air shroud
- 1200W redundant Titanium level 100-240Vac and 200-240 Vdc power supplies
- 1 VGA, 1 COM, 2 USB 3.0 (rear)
|
- Brand: SUPERMICRO
- Generatie: X13
- Procesor: INTEL
- compari: Server
