Dual AMD EPYC™ 7003/7002 Series Processors
(7003 Series Processor drop-in support requires BIOS version 2.0 or newer)
Socket SP3
Support CPU TDP / cTDP up to 200W*
Cores
Up to 64 Cores
Note
* Certain CPUs with high TDP may be supported only under specific conditions. Please contact Supermicro Technical Support for additional information about specialized system optimization
System Memory (per Node)
Memory Capacity
16 DIMM slots
Supports up to 4TB Registered ECC DDR4 3200MHz SDRAM in 16 DIMMs
8-channel memory bus
For Dual CPUs: Recommended that memory be populated equally in adjacent memory banks
1 PCI-E 4.0 x16 SIOM LAN Networking Slot for flexible networking, see SIOM LAN options support matrix (Must bundle with at least one SIOM network card)
IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Operating Temperature:
10°C ~ 30°C (50°F ~ 86°F)
* Support for operating above 30°C is available in certain system configurations. Contact your Supermicro sales rep or Technical Support for more details.
Non-operating Temperature:
-40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity:
8% to 90% (non-condensing)
Non-operating Relative Humidity:
5% to 95% (non-condensing)
Titanium Level
