SKU: MGB-2GTRJ
| MGB-2GTRJ | |
|---|---|
| PHY Type | 2500BASE-X |
| Connector | RJ45 Copper |
| DDM | Yes |
| Maximum Distance | 100m |
| Operating Temperature | -40~85 degrees C |
| Storage Temperature | -40~85 degrees C |
| MGB-2GTSR | |
| PHY Type | 2500BASE-X |
| Fiber Type | Multi-mode |
| Connector | Dual LC/UPC |
| DDM | Yes |
| Wavelength | 850nm |
| Maximum Distance | 300m |
| Operating Temperature | -40~85 degrees C |
| Storage Temperature | -40~85 degrees C |
| MGB-2GTLA20 | |
| PHY Type | 2500BASE-X |
| Fiber Type | Single-mode |
| Connector | Simplex LC/UPC |
| DDM | Yes |
| Wavelength | TX1310nm, RX1550nm |
| Maximum Distance | 20km |
| Operating Temperature | -40~85 degrees C |
| Storage Temperature | -40~85 degrees C |
| MGB-2GTLB20 | |
| PHY Type | 2500BASE-X |
| Fiber Type | Single-mode |
| Connector | Simplex LC/UPC |
| DDM | Yes |
| Wavelength | TX1550nm, RX1310nm |
| Maximum Distance | 20km |
| Operating Temperature | -40~85 degrees C |
| Storage Temperature | -40~85 degrees C |
| MGB-2GLR2 | |
| PHY Type | 2500BASE-X |
| Fiber Type | Single-mode |
| Connector | Duplex LC/UPC |
| DDM | Yes |
| Wavelength | 1310nm |
| Maximum Distance | 2km |
| Operating Temperature | 0~70 degrees C |
| Storage Temperature | -40~85 degrees C |
| MGB-2GLR20 | |
| PHY Type | 2500BASE-X |
| Fiber Type | Single-mode |
| Connector | Duplex LC/UPC |
| DDM | Yes |
| Wavelength | 1310nm |
| Maximum Distance | 20km |
| Operating Temperature | 0~70 degrees C |
| Storage Temperature | -40~85 degrees C |
| MGB-2GSR | |
| PHY Type | 2500BASE-X |
| Fiber Type | Multi-mode |
| Connector | Dual LC/UPC |
| DDM | Yes |
| Wavelength | 850nm |
| Maximum Distance | 300m |
| Operating Temperature | 0~70 degrees C |
| Storage Temperature | -40~85 degrees C |
| MGB-2GLA20 | |
| PHY Type | 2500BASE-X |
| Fiber Type | Single-mode |
| Connector | Simplex LC/UPC |
| DDM | Yes |
| Wavelength | TX: 1310nm, RX:1550nm |
| Maximum Distance | 20km |
| Operating Temprature | 0~70 degrees C |
| Storage Temperature | -40~85 degrees C |
| MGB-2GLB20 | |
| PHY Type | 2500BASE-X |
| Fiber Type | Single-mode |
| Connector | Simplex LC/UPC |
| DDM | Yes |
| Wavelength | TX:1550nm, RX:1310nm |
| Maximum Distance | 20km |
| Operating Temperature | 0~70 degrees C |
| Storage Temperature | -40~85 degrees C |
| MGB-2GTLR2 | |
| PHY Type | 2500BASE-X |
| Fiber Type | Single-mode |
| Connector | Duplex LC/UPC |
| DDM | Yes |
| Wavelength | 1310nm |
| Maximum Distance | 2km |
| Operating Temperature | -40~85 degrees C |
| Storage Temperature | -40~85 degrees C |
| MGB-2GTLR20 | |
| PHY Type | 2500BASE-X |
| Fiber Type | Single-mode |
| Connector | Duplex LC/UPC |
| DDM | Yes |
| Wavelength | 1310nm |
| Maximum Distance | 20km |
| Operating Temperature | -40~85 degrees C |
| Storage Temperature | -40~85 degrees C |
